Red and Green Chevron Integrated LED in White
You last purchased this on
Lithonia Lighting
ECR Series Red and Green Chevron Integrated LED in White
Purchase history
Lithonia Lighting
ECR Series
Red and Green Chevron Integrated LED in White
ECRG SQ M6
Order #
Order Date
Job Name
My PO#
Frequently Purchased Together
Product Details
Product Details
- The Lithonia Lighting Basics™ ECRG, is a combination of exit and emergency lighting. The ECRG is ideal for safely illuminating the path of egress above-the-door in small spaces at lower mounting heights while providing 90 minutes of emergency power. Contains ability to switch between red and green letters.
- The EXRG LED Exit Sign has an internal switch for red or green color selection
- Offered in the new bright white thermoplastic housing, the EXRG has a classic design with updated features. This fully assembled single-face exit comes with an extra faceplate and red and green panel inserts for ultimate field configurability.
- Dual-voltage 120/277, 60Hz
- UL Listed, Meets all applicable requirements for UL 924, NFPA 101 (current Life Safety Code), NFPA 70 (NEC), FCC Title 47, Part 15, Subpart B and OSHA, Indoor damp location 50°F to 104°F (10°C to 40°C) listed
- Top, side and back mount. Mounting pattern on canopy (top and side mount) and back plate (back mount) fits most standard size junction boxes
- The typical life of the LED lamp is 10 years
- Provides a minimum of 90 minutes illumination for the rated wattage upon loss of AC power to meet code required emergency lighting
- BATTERY: 3.6V maintenance-free, rechargeable, nickel metal hydride
- 2-year limited warranty
Specifications
- Average Life:
- 10 yr
- Battery Type:
- NiCad
- Collection:
- ECR Series
- Color Finish Category:
- Whites
- Color Finish Name:
- White
- Depth:
- 8-9/20 in
- Directional Indicators:
- Chevron
- Emergency Battery Backup:
- Yes
- Height:
- 7-19/20 in
- Installation Type:
- Ceiling Mount, Wall Mount
- Length:
- 19-9/100 in
- Letter Color:
- Red/Green
- Lettering:
- Exit
- Light Bulb Type:
- Integrated LED
- Material:
- Die Cast Aluminum, Plastic
- Material Type:
- Thermoplastic
- Number Of Hours:
- 50000 h
- Number of Faces:
- 1
- Number of Lights:
- 2
- Power Source:
- AC, Battery
- UL Listed:
- Yes
- Volts:
- 120/277V
- Watts:
- 3.8 W
- Width:
- 4-33/100 in
