Name: UPBA485B Series 2-1/2 in. Brass FPT 400# Full Port Ball Valve
Availability: InStock

Milwaukee Valve

Fast #
Part #MUPBA485BL
Item #7049639
Manufacturer Part #UPBA-485B - 212

$1,250.24

EACH

Valve Size: 2-1/2 in

Add $45.00 more to cart to get FREE Shipping

Pick Up: Not available
Shipping: Available for immediate shipment

Frequently Purchased Together

Product Details

Bubble-Tight Shutoff
Quarter Turn Operation
Ultrapure low lead

Lead Law Compliant

Documents

INSTALLATION

SPECIFICATION

Specifications

ANSI:: ANSI 372, ANSI 61

ASME:: ASME A112.4.14

ASTM:: ASTM B-283 C27450

BAA Compliant:: No

CSA Certified:: No

Clean Bagged:: No

Collection:: UPBA485B Series

Color Finish Name:: Brass

End Connection 1:: Sweat

End Connection 2:: Sweat

End Connections:: Sweat

FM Approved:: No

Fire Suppression System Rated:: No

Handle Length (in):: 7-87/100 in

Handle Material:: Zinc Plated Steel

Handle Type:: Lever

Height:: 3-47/50 in

IAPMO Listed:: Yes

ISO:: ISO 9001, ISO 14001

Lead Law Compliance Level:: Lead Law Compliant and Certified

Lead Law Compliant:: Yes

Length:: 7-1/4 in

MA Approved:: Yes

MSS:: MSS SP-110

Material:: Forged Brass, Lead Free Brass

Maximum Temperature:: 250

Minimum Temperature:: -20

NSF:: NSF 61, NSF 372

NSF Certified:: Yes

Number of Pieces:: 2 Piece

Origin:: Global

Pressure - High:: 400

Pressure - Low:: 0

Pressure - Maximum:: 400 psig

Pressure Class:: 400#

Proposition 65:: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Recommended Valve Application:: Potable Water

Temperature Range:: -20 to 250 Deg F

Temperature Rating:: 250

UL Listed:: No

Valve Body Material:: Forged Brass

Valve Body Style:: 2 piece

Valve Disc Material:: Chrome Plated Brass

Valve Operator:: Lever Handle

Valve Port Opening:: Full Port

Valve Seat Material:: PTFE

Valve Size:: 2-1/2 in

Valve Stem:: Blowout-proof

Valve Type:: Ball Valve

Weight:: 12.22 lb

Width:: 2-1/2 in

cUPC Certified:: No
