10 in. Ductile Iron Grooved EPDM Gear Operator Handle Butterfly Valve
You last purchased this on
NIBCO
GD-4765 Series 10 in. Ductile Iron Grooved EPDM Gear Operator Handle Butterfly Valve
Purchase history
NIBCO
GD-4765 Series
10 in. Ductile Iron Grooved EPDM Gear Operator Handle Butterfly Valve
NLK690M
Order #
Order Date
Job Name
My PO#
Frequently Purchased Together
Product Details
Product Details
- Geometric drive
- Operating mechanism: Bare stem, infinite position plate and lock, lever lock, manual gear operator
- Molded-in seat liner eliminates leakage between body and liner as in cartridge or boot type liners
- Valve pressure rating 300 psi (2 in. to 10 in.); 200 psi (12 in. only)
- Max temperature rating 200°F
- Grooved style
- EPDM encapsulated ductile iron disc
- Splined drive
- Extended neck
- Not recommended for steam service
Specifications
- ANSI:
- ANSI 372, ANSI 61
- ASTM:
- ASTM A395, ASTM A582 Type 416
- Coating:
- Polyamide
- Collection:
- GD-4765 Series
- End Connection 1:
- Grooved
- End Connection 2:
- Grooved
- End Connections:
- Grooved
- FM Approved:
- No
- Length:
- 6-29/100 in
- MSS:
- MSS SP-25, MSS SP-67
- Material:
- Ductile Iron
- Maximum Temperature:
- 200
- NSF:
- NSF 372, NSF 61
- NSF Certified:
- Yes
- Pressure - High:
- 300
- Pressure Class:
- 300#
- Proposition 65:
- WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
- Recommended Valve Application:
- Commercial, HVAC, Industrial, Potable Water
- UL Listed:
- No
- Valve Body Material:
- Ductile Iron
- Valve Body Style:
- 1 piece
- Valve Disc Material:
- Ductile Iron, EPDM
- Valve Operator:
- Gear Operator
- Valve Seat Material:
- EPDM
- Valve Size:
- 10 in
- Valve Type:
- Butterfly Valve
- Width:
- 11-1/4 in
