4 in. 150# RF FLG CF8M T10 Globe Valve PTFE Packing, ASME B16.34, Stainless Steel 316 Body, Trim 10, Bolted Bonnet
You last purchased this on
Warren Valve LP
Figure 2156 4 in. 150# RF FLG CF8M T10 Globe Valve PTFE Packing, ASME B16.34, Stainless Steel 316 Body, Trim 10, Bolted Bonnet
Purchase history
Warren Valve LP
Figure 2156
4 in. 150# RF FLG CF8M T10 Globe Valve PTFE Packing, ASME B16.34, Stainless Steel 316 Body, Trim 10, Bolted Bonnet
2156 4
Order #
Order Date
Job Name
My PO#
Frequently Purchased Together
Product Details
Product Details
- Warren Valve’s line of cast stainless steel & alloy globe valves are offered in classes 150, 300, 600, 900, and 1500
- For oil and gas refineries and petrochemical plants, Warren’s stainless steel & alloy valves are an economical and quality choice Warren Valves are subject to rigorous quality inspections
Documents
Specifications
- ANSI:
- ANSI 304, ANSI B16.10, ANSI B16.34, ANSI B16.47 Series A, ANSI B16.512
- ASTM:
- ASTM A-194 Grade 8M, ASTM A-216 Grade WCB, ASTM A-240 Grade 304, ASTM A-276 Grade 316, ASTM A-351 Grade CF8M, ASTM A-439 D2, ASTM A-536, ASTM A-666 Grade 304
- Collection:
- Figure 2156
- End Connection 1:
- Flanged
- End Connection 2:
- Flanged
- End Connections:
- Flanged
- Handle Material:
- Ductile Iron
- Length:
- 11-1/2 in
- MSS:
- MSS SP-44, MSS SP-55
- Material:
- Stainless Steel, Plastic
- Material Type:
- 316L, CF8M, PTFE
- NSF Certified:
- No
- Pressure Class:
- 150#
- UL Listed:
- No
- Valve Body Material:
- CF8M
- Valve Disc Material:
- CF8M
- Valve Operator:
- Hand Wheel
- Valve Port Opening:
- Full Port
- Valve Seat Material:
- PTFE
- Valve Size:
- 4 in
- Valve Type:
- Globe Valve
