1-1/4 in. Forged Brass Full Port Female Socket 600# Ball Valve

Webstone a brand of NIBCO

10170W Series 1-1/4 in. Forged Brass Full Port Female Socket 600# Ball Valve

  • Fast #
  • Part #WH101705W
  • Item #7340509
  • Manufacturer Part #H-101705W
4.5 out of 5 Customer Rating
Brand image
Webstone a brand of NIBCO Blue Forged Brass Full Port Female PP-R Metric Socket 600# Ball Valve
Webstone a brand of NIBCO Blue Forged Brass Full Port Female PP-R Metric Socket 600# Ball Valve
Webstone a brand of NIBCO

10170W Series 1-1/4 in. Forged Brass Full Port Female Socket 600# Ball Valve

  • Fast #
  • Part #WH101705W
  • Item #7340509
  • Manufacturer Part #H-101705W
4.5 out of 5 Customer Rating
X Points

EACH
Pro Pricing Displays discounted prices List Pricing Displays catalog prices No Pricing Removes prices from page

Package Quantity Info:

Each: 1 Inner Pack: 1
Unavailable
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
Looking for compatible parts?
How to get it:
  • Pick Up   Not Available
    0  in  Hilliard, OH
    0 nearby
  • Shipping Not Available
    Not available at this time

Product Details

Product Details

  • Permanent leak-free heat fused connections made in seconds
  • Compatible with all Aquatherm® PP-R piping systems
  • Safe, clean, long-lasting, high performance materials
  • Suitable for all potable applications
  • Saves labor, space and leak paths
  • Full port forged brass ball valves with adjustable packing gland & reversible handle
  • Lead free
  • Female PP-RCT metric socket
  • Manufactured for use with all PP-R & PP-RCT piping systems
  • Max. operating pressure: 600 psi
  • Requires Certification

  • Lead Law Compliant

Specifications

ANSI:
ANSI 372, ANSI 61
ASTM:
ASTM F-2389
Collection:
10170W Series
End Connection 1:
Female Socket Weld
End Connection 2:
Female Socket Weld
End Connections:
Female Socket Weld
FM Approved:
No
Handle Material:
Steel
Height:
3 in
IAPMO Listed:
No
ISO:
ISO 9001
Lead Law Compliance Level:
Lead Law Compliant and Certified
Lead Law Compliant:
Yes
Length:
5-3/4 in
Material:
Forged Brass, Plastic
Material Type:
PTFE
Maximum Temperature:
180
NSF:
NSF 372, NSF 61
NSF Certified:
Yes
Origin:
Global
Pressure - High:
600
Pressure Class:
600#
Recommended Valve Application:
Gas, Oil, Potable Water
UL Listed:
No
UPC:
018394011182
Valve Body Material:
Forged Brass
Valve Body Style:
Ball
Valve Operator:
Quarter Turn Lever Handle
Valve Port Opening:
Full Port
Valve Seat Material:
PTFE
Valve Size:
1-1/4 in
Valve Stem:
Blowout-proof
Valve Type:
Ball Valve
Weight:
2.42 lb
