Webstone a brand of NIBCO 1 in. Brass Full Port Threaded 600# Ball Valve | Ferguson

Ferguson.com no longer supports Internet Explorer. If you continue using IE, your experience will be degraded and you will not be able to check out. To use Ferguson.com, please use one of the following browsers: Chrome, Safari, Firefox, or Edge.

Skip to main content Skip to footer content

Webstone a brand of NIBCO

Webstone a brand of NIBCO

Fast #
Part #WH48614
Item #4108368
Manufacturer Part #H-48614

$97.20

EACH

Valve Size: 1 in

Add $45.00 more to cart to get FREE Shipping

Pick Up: Not available
Shipping: Available for immediate shipment

Frequently Purchased Together

Product Details

Simultaneously drain, flush and refill any hydronic, solar, or closed loop system
Reversible handle for added versatility
Specifically designed for filling and draining glycol/antifreeze from any point in a hydronic system
This valve is actuated by a blowout proof stem
Adjustable packing gland
Patented technology
Available in FIP, SWT, PRS
Certified to NSF/ANSI 61
Saves 54 minutes
Replaces 7 components

Not Compliant, Approved for Non-Potable Water Applications

Documents

INSTALLATION

CAD_DRAWING

WARRANTY

SPECIFICATION

Specifications

ANSI:: ANSI B1.20.1

BAA Compliant:: No

Clean Bagged:: No

Collection:: Pro-Pal Series® Purge and Fill™

Color Finish Name:: Brass

Depth:: 8-1/10 in

End Connection 1:: NPT

End Connection 2:: NPT

End Connection 3:: NPT

End Connection 4:: NPT

End Connections:: NPT

FM Approved:: No

Fire Suppression System Rated:: No

Handle Material:: Chrome Plated Steel

Handle Type:: Lever

Height:: 2-4/5 in

IAPMO Listed:: No

ISO:: ISO 9001

Lead Law Compliance Level:: Not Compliant, Approved for Non-Potable Water Applications

Length:: 4-5/16 in

MA Approved:: No

Material:: Brass

Maximum Temperature:: 350

NSF Certified:: No

Origin:: Global

Pressure - High:: 600

Pressure - Maximum:: 600 psi

Pressure Class:: 600#

Recommended Valve Application:: Commercial, Gas, Industrial, Oil, Residential, Potable Water

Temperature Rating:: 250

UL Listed:: No

Valve Body Material:: Forged Brass

Valve Body Style:: Ball

Valve Operator:: Lever Handle

Valve Port Opening:: Full Port

Valve Seat Material:: PTFE

Valve Size:: 1 in

Valve Stem:: Blowout-proof

Valve Type:: Ball Valve

Weight:: 2.06 lb

Width:: 4 in

cUPC Certified:: No
