NIBCO

NIBCO Polished Chrome DZR Silicon Bronze Conventional Port Solder 600# Ball Valve

NIBCO

Fast #
Part #NS58080LFM
Item #4697987
Manufacturer Part #NJ830XF

$781.44

EACH

Valve Size: 3 in

Out of Stock

Pick Up: Not available
Shipping: Not available

Frequently Purchased Together

Product Details

Valve pressure rating 600 psi/41.4 bar non-shock cold working pressure
Max temperature rating 300° F
Full port
Silicon Performance Bronze® body, ball and stem
Dezincification resistant
Standard lever handle, optional NIB-SEAL®, locking lever, memory stop, extended lever, round and wing
Solder end connections
The NIBCO® bronze ball valve provides ease of operation with quarter-turn (90°) open to close
The two-piece valve features solder ends for easy installation
Choose NIBCO® ball valves for the most specified, versatile and economical valve option in commercial, residential, mechanical and industrial applications

Lead Law Compliant

Documents

INSTALLATION

SPECIFICATION

WARRANTY

Specifications

ANSI:: ANSI 372, ANSI 372-8, ANSI 61, ANSI 61-8, ANSI Z1157

ASTM:: ASTM B16, ASTM B-283, ASTM B-371, ASTM B-584

Collection:: S-580-80-LF

End Connection 1:: Female Sweat

End Connection 2:: Female Sweat

End Connections:: Female Sweat

FM Approved:: No

Handle Material:: Plated Steel

Height:: 6-61/100 in

IAPMO Listed:: Yes

Lead Law Compliance Level:: Lead Law Compliant and Certified

Lead Law Compliant:: Yes

Length:: 7-53/100 in

MSS:: MSS SP-110, MSS SP-145

Material:: Bronze, Plastic, Steel

Material Type:: RPTFE

NSF:: NSF 372, NSF 372-8, NSF 61, NSF 61-8

NSF Certified:: Yes

Origin:: Domestic

Pressure - High:: 600

Pressure Class:: 600#

Proposition 65:: WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov

Recommended Valve Application:: Potable Water

Temperature Rating:: 300

UL Listed:: No

Valve Body Material:: Bronze

Valve Body Style:: 2 piece

Valve Operator:: Lever Handle

Valve Port Opening:: Standard Port

Valve Seat Material:: Reinforced PTFE

Valve Size:: 3 in

Valve Stem:: Blowout-proof

Valve Type:: Ball Valve

Weight:: 13.75 lb

Width:: 7-53/100 in

cUPC Certified:: Yes
